Discover the World of 3D Printing |Large Automatic High Quality FDM 3D Printer With Dual Nozzle
The Professional FDM 3D Printing Machine With Dual Extruders is designed for engineers, designers, and manufacturers who demand industrial-grade precision and speed. Featuring a fully enclosed structure, independent dual extruder (IDEX) system, and support for a wide range of technical filaments, this printer delivers consistent, high-quality results. With print speeds reaching up to 500mm/s and advanced temperature control up to 350°C, it offers a powerful platform for rapid prototyping, multi-material prints, and high-performance applications. Know more..
General Specifications
| Specification | Details |
|---|---|
| Product Name | High Speed FDM 3D Printing Machine with Dual Nozzles |
| Print Technology | FDM (Fused Deposition Modeling) |
| Build Volume | 400×400×400 mm |
| Print Accuracy | 0.1 mm |
| Max Print Speed | 500 mm/s |
| Recommended Print Speed | 200–300 mm/s |
| Nozzle Temperature | ≤350°C (Recommended ≤320°C) |
| Platform Temperature | ≤110°C |
| Max Flow | 40 mm³/s |
| Nozzle Diameter | 0.4 mm (Optional: 0.6, 0.8, 1.0 mm) |
| Extruder Type | IDEX (Independent Dual Extruders) |
| Copy Mode | 400(2×200)×400×400 mm |
| Mirror Mode | 320(2×160)×400×400 mm |
| Machine Dimensions | 690×790×910 mm |
| Weight | 107 kg |
Materials & Compatibility
| Specification | Details |
|---|---|
| Filament Diameter | 1.75 mm |
| Build Material | Other |
| Filament Type | Plastic |
| Hot Bed Material | PEI |
| Common Filaments | PLA, TPU, PETG |
| Engineering Filaments | PA-CF/GF, PET-CF/GF, HtPA-CF/GF, ABS-GF25, ABS-CF20, PA-GF25/CF25 |
| Support Filaments | S-Mulit, S-HtPA, PVA, etc. |
| Support Material | PA-CF/GF, PET-CF, HtPA-CF/GF, ABS-GF25, ABS-CF20, PA-GF25, PETG, S-HtPA, PVA |
Electrical & Software
| Specification | Details |
|---|---|
| Input Voltage | 100/240V AC, 50/60Hz |
| Rated Power | 800W |
| Display Screen | 7-inch HDMI Touch Screen |
| Firmware | Klipper |
| Support Software | Mingda OrcaSlicer, Prusa Slicer, etc. |
| Operating Systems | Other, Linux, macOS, Windows OS |
| Connectivity | WiFi, Type-C, U-Disk, SD Card |
| Plug Specifications | US Plug, UK Plug, AU Plug, Japan Plug, EU Plug |
Additional Details
| Specification | Details |
|---|---|
| Production Capacity | 10,000 pcs/month |
| Warranty | 1 Year |
| Application | Industrial, Dual Color Printing, Rapid Prototyping |
| Features | Multi-axis, Heated Bed, Dual Extruder, Resume Printing, Filament Detection, Auto Leveling, PEI, IDEX System, Fully Enclosed Metal Structure, 350°C High Temp, Fast Print, Air Filtration System |
| Automatic Grade | Automatic |
| Color & Page | Two Colors |
| Voltage | 220V/110V |
| Plate Type | Flatbed |
| Input Power | Power Adapter |
Why Choose the Professional FDM 3D Printing Machine With Dual Extruders?
🔹 Large build volume of 400×400×400mm for industrial-grade prints
🔹 High-speed printing up to 500mm/s with 40mm³/s flow rate
🔹 IDEX dual extruder system for copy and mirror mode capabilities
🔹 PEI-coated heated bed ensures excellent first-layer adhesion
🔹 Compatible with PLA, ABS, Nylon, PETG, PA-CF, PET-CF, and more
🔹 Enclosed structure with air filtration for stable and clean printing
🔹 7-inch HDMI touchscreen with Klipper firmware for seamless control
🔹 Ideal for rapid prototyping, functional parts, and dual-color prints
🔹 Advanced slicer support including Mingda OrcaSlicer and Prusa Slicer
🔹 Robust metal frame for durability and minimal vibration
🔹 Production capacity up to 10,000 units per month
Order Now – Get Your Professional FDM 3D Printing Machine With Dual Extruders Today!
Unlock industrial-grade performance with the FDM 3D Printing Machine With Dual Extruders — built for speed, precision, and versatility. Whether you’re printing complex prototypes or dual-color models, this machine delivers reliable, high-quality results with every print.
