Discover the World of 3D Printing |Lightweight PLA Areo Best Filament for Aircraft Model
The Lightweight PLA Aero Best Filament for Aircraft Model is engineered for creators who demand precision, strength, and reduced weight in their aerodynamic builds. Perfect for drone parts, RC planes, and aerospace-grade prototypes, it offers excellent printability, stable foaming at high temperatures, and up to 122% volume expansion—making it the ideal filament for professionals in aviation modeling. Know more..
Physical Properties of PLA-Aero
| Test Item | Test Method/Standard | Parameter |
|---|---|---|
| Melt Index | GB/T 3682-2000 | 8.1 (190°C/2.16kg) |
| Density | GB/T 1033-86 | 1.21 g/cm³ |
| Izod Notched Impact Strength | GB/T 1843-96 | 8.58 kJ/m² |
| Tensile Strength | GB/T 1040-92 | 32.2 MPa |
| Elongation at Break | GB/T 1040-92 | 68.9% |
| Bending Strength | GB/T 9341-2000 | 41.31 MPa |
| Flexural Modulus | GB/T 9341-2000 | 1701 MPa |
PLA-Aero Print Parameters
| Parameter | Value |
|---|---|
| Material Name | PLA-Aero |
| Recommended Printing Temperature | 190–270°C |
| Unfoamed Printing Temperature | 190–210°C |
| Foamed Printing Temperature | 210–270°C |
| Maximum Foaming Temperature | 270°C |
| Maximum Foaming Rate (at 270°C) | 122% |
| Minimum Extrusion Rate (at 270°C) | 45% |
| Bottom Plate Temperature | 45–60°C / no heating |
| Compatible Print Surfaces | Textured paper, PVP glue, glass board, carbon fiber board, PEI |
| Printing Speed | 40–80 mm/s |
Printing Test Conditions
| Parameter | Value |
|---|---|
| Nozzle Temperature Range | 190–280°C |
| Layer Height | 0.2 mm |
| Bed Temperature | 45°C |
| Speed | 40 mm/s |
Foaming Performance vs Temperature
| Temperature (°C) | Foaming Rate (%) | Volume Magnification (%) | Extrusion Rate (%) | Density (g/cm³) |
|---|---|---|---|---|
| 200 | 0 | 100 | 100 | 1.20 |
| 210 | 0 | 100 | 100 | 1.20 |
| 220 | 11 | 111 | 90 | 1.08 |
| 230 | 33 | 133 | 75 | 0.90 |
| 240 | 82 | 182 | 75 | 0.66 |
| 250 | 100 | 200 | 55 | 0.60 |
| 260 | 122 | 222 | 55 | 0.54 |
| 270 | 122 | 222 | 50 | 0.54 |
| 280 | 22 | 182 | 45 | 0.66 |
Why Choose the Lightweight PLA Areo Best Filament for Aircraft Model?
🔹 Extremely lightweight with up to 122% foaming rate at 270°C — perfect for reducing weight in flight models
🔹 Excellent impact resistance with an Izod notched impact strength of 8.58 kJ/m²
🔹 Maintains high tensile strength (32.2 MPa) and flexural strength (41.31 MPa) even after foaming
🔹 Broad printing temperature range (190–270°C) offers versatility for different model needs
🔹 High volume magnification helps reduce material usage without sacrificing structure
Application of Lightweight PLA Areo Best Filament for Aircraft Model
🔹RC Aircraft and Drone Parts – Wings, fuselages, propeller guards, and lightweight internal structures
🔹Aerospace Prototyping – Concept models, aerodynamic simulations, and airflow testing components
🔹UAV Structural Components – Lightweight frames and protective housings for unmanned aerial vehicles
🔹Glider Models – Ultra-light parts requiring high lift-to-weight ratio
🔹Wind Tunnel Models – Scaled aerodynamic test objects where accurate shape and low mass are key
🔹Educational Aviation Kits – Classroom-friendly prints for aerodynamics and flight mechanics
🔹Custom Hobby Aircraft Projects – DIY flight builds and experimental designs requiring fine-tuned balance
With its high-temperature resistance, structural integrity, and dramatic foaming capacity, PLA Aero is the top choice for 3D printed aviation models.
Order Now – Get Your Lightweight PLA Areo Best Filament for Aircraft Model Today!
Unlock the full potential of your aircraft model designs with the Lightweight PLA Aero filament. Whether you’re building RC planes, UAV parts, or aerospace prototypes, this filament delivers superior strength-to-weight performance. Don’t miss out—upgrade your prints with precision and efficiency today!
