Discover the World of 3D Printing |Large Format SLM 3D Printer For Large Model Prototyping
The iSLM160 Large Format SLM 3D Printer for Large Model Prototyping is a powerful industrial solution built to meet the demands of modern manufacturing and innovation. Designed for professionals who require both size and precision, this advanced metal 3D printer combines high-powered laser systems, fast scanning speeds, and a spacious build volume to produce large, complex components with exceptional detail and strength. Perfect for aerospace, automotive, and heavy industry applications, it offers unmatched flexibility, efficiency, and reliability in large-scale metal part production. Know more..
LASER SYSTEM
| Feature |
Specification |
| Type |
YB-Fiber Laser (IPG) |
| Wavelength |
1064nm |
| Laser Power |
200W / 500W (optional) |
RECOATING SYSTEM
| Feature |
Specification |
| Process |
Two-way variable speed synchronous coating |
| Normal Build Style |
0.03mm |
| Quick Build Style |
0.04–0.10mm |
| Precision Build Style |
0.02–0.03mm |
OPTICAL & SCANNING
| Feature |
Specification |
| Beam Diameter (Φ) |
0.05–0.15mm |
| Focus Style |
Scan Lab High-speed Galvanometer |
| Part Scan Speed |
Recommended 2.0 m/s |
| Beam Jump Speed |
Recommended 10.0 m/s |
ELEVATOR
| Feature |
Specification |
| Vertical Resolution |
0.0002mm |
| Max Part Weight |
10KG |
| Max Build Speed¹ |
15 cm³/h |
| Drive Way |
Servo Motor Precision Deceleration Drive |
POWDER VAT
| Feature |
Specification |
| Volume |
Approx. 5.2L |
| Fixed Substrate Plate |
Quick replacement without screw holes (transition tank quick exchange) |
| Forming Size |
160mm (X) × 160mm (Y) × 200mm (Z) |
| Gas Shielded |
Nitrogen, Argon |
| Heating Style |
Precision Resistance Wire Heating |
SOFTWARE
| Feature |
Specification |
| Operating System |
Windows 10 Pro, Ethernet, IEEE802.3 |
| Build Software |
ZERO 4.0 PRESTO Software |
| CAD Interface |
3D Design Software, STL File Format |
INSTALLATION CONDITIONS
| Feature |
Specification |
| Power |
200–240VAC 50/60Hz, Single-phase, 12Amps |
| Ambient Temperature |
20–26ºC |
| Relative Humidity |
Less than 40%, non-condensing |
| Size |
1.10m (W) × 1.28m (D) × 1.85m (H) |
| Weight |
Approx. 850 Kg |
WARRANTY
| Component |
Coverage |
| Laser |
5000 hours or 12 months (whichever comes first) |
| Main Machine |
1 year from the installation date |
Why Choose the Large Format SLM 3D Printer?
🔹 Optional 200W or 500W YB-Fiber Laser (IPG) with 1064nm wavelength
🔹 Build volume of 160×160×200mm with approx. 5.2L powder vat
🔹 ScanLab high-speed galvanometer with up to 2.0 m/s part scan speed
🔹 Precision servo motor elevator with 0.0002mm vertical resolution
🔹 Quick substrate plate replacement without screws for fast turnaround
🔹 Two-way variable speed synchronous recoating system
🔹 Build software: ZERO 4.0 PRESTO, supports STL file format
🔹 Layer thickness options from 0.02mm to 0.10mm
🔹 Gas shielding with Nitrogen or Argon for stable metal printing
🔹 12-month machine warranty & 5000-hour laser warranty
Order Now – Get Your Large Format SLM 3D Printer For Large Model Prototyping Today!
Order now and elevate your prototyping capabilities with the iSLM160 Large Format SLM 3D Printer – designed specifically for large model production with unmatched precision and performance. With advanced laser technology, high-speed scanning, and a generous build volume, this industrial-grade solution ensures consistent results, faster turnarounds, and greater design freedom. Whether for aerospace, automotive, or tooling, it’s the ideal machine to bring your complex metal parts to life with efficiency and reliability.
